The Project

The S.A.R.T. is designed as a disposable, rapidly manufactured and cheap remote inspection vehicle that can be deployed in any situation where it is difficult or dangerous to send in human personnel. From search and rescue to disaster response to inspection of tunnels and pipelines, S.A.R.T. robots are equipped with arrays of sensors and cameras to report the situation to personnel on the scene.

Open Source

The S.A.R.T. project is completely open source. All our code and design files, as well as tutorials and useful information is available on our website, Github and Thingiverse. You can check out the downloads page here. By keeping the project open, we hope to faciliate the development of rapidly manufactured first response robots worldwide, contributing to the global goal of saving lives.

S.A.R.T Interface

The S.A.R.T robot is controlled via a dashboard called the S.A.R.T Interface. Features include multiple video streams, providing a 360° view, live sensor data including thermal imagery, direct access to the robot through SSH console, and much more. Users never have to access the S.A.R.T hardware directly – everything can be done within the interface. See the demo here!

Complete Documentation

We provide extensive documentation on all our design and construction processes when it comes to coding, modelling, building, and coming up with new ideas. You could build your own S.A.R.T simply using the information provided in our daily blog.

Also available is the comprehensive 2020 Q1 S.A.R.T. TDM.

The Future

We have many plans to expand the versatility of the S.A.R.T robot. We are creating a “base model” that other people can develop on top of thanks to our Open Source philosophy.

Awards & Recognition

We often enter our robots in competitions such as RoboCup. We have received awards and recognition for a number of achievements and advances.

  • Tied 1st Place – Rapidly Manufactured Rescue League, RoboCup 2016, Leipzig, Germany
  • 1st Place – Rapidly Manufactured Rescue League, RoboCup 2017, Nagoya, Japan
  • Open Source Award – Rapidly Manufactured Rescue League, RoboCup 2017, Nagoya, Japan
  • Open Source and Innovation Award – Rapidly Manufactured Rescue League, RoboCup 2018, Montréal, Canada

Specifications

S.A.R.T Mark IV

Drive System2x Dynamixel AX-18A Servo
Computational UnitNVIDIA Jetson Nano
Central ProcessorQuad-core ARM A57 @ 1.43 GHz
Onboard StoragemicroSD
RAM4 GB 64-bit LPDDR4
Camera System3x ELP 5MP HD USB Camera
1x Pimoroni MLX90640 Thermal Camera
Mapping SystemLDS-01 LIDAR Laser Distance Sensor
Additional SensorsAir Quality (VOC and eCO2), Temperature
Human CommunicationTwo-way Stereo Audio
Manipulator60 cm Arm & Claw, 4 Degrees of Freedom
Control SystemS.A.R.T. Interface (Keyboard, Controller)

S.A.R.T Mark III

Drive System4x Dynamixel AX-18A Servos
Computational UnitUDOO x86 Ultra
Central ProcessorIntel Pentium N3710 @ 2.56GHz x4
Onboard Storage32GB Integrated eMMC
RAM8GB
Camera System4x ELP 5MP USB Camera, 1x Thermal Camera
Mapping System4x Adafruit VL53L0X Time-Of-Flight Sensor
Additional SensorsAir Quality (VOC and eCO2), Temperature
Human CommunicationTwo-way Audio
Control SystemS.A.R.T. Interface

S.A.R.T Mark II

Drive System4x Dynamixel AX-18A Servos
Computational UnitIntel NUC NUC5CPYH
Central ProcessorIntel Celeron N3050 @ 2.16GHz x2
Onboard Storage120GB SAMSUNG SSD
RAM4GB
Camera SystemoCam 5MP USB 3.0 Camera
Mapping System4x SHARP GP2Y0A21YK0F Infared Sensor
Additional SensorsTemperature, Accelerometer, Compass
Human CommunicationText to Speech, Speech to Text
Control SystemS.A.R.T. Interface

S.A.R.T Mark I

Drive System4x Dynamixel AX-12A Servos
Computational UnitRaspberry Pi 3
Onboard Storage32GB SD
RAM1GB
Camera SystemRaspberry Pi Camera Board
Control SystemPlayStation Controller
